Ultra Bright SMD 5050 LED Chips , Led Single Chip Red Color 2 Years Warranty

Ultra Bright SMD 5050 LED Chips , Led Single Chip Red Color 2 Years Warranty

Place of Origin: SHENZHEN
Brand Name: Yuhang
Certification: CE.SGS.ROHS
Model Number: YH5050R05
Minimum Order Quantity: 6K
Delivery Time: 5-7 work days
Payment Terms: T/T, Western Union,Paypal
Supply Ability: 8KK/Days

Detailed Product Description

Type:	smd led	Chip Material:	InGaN
Emitting Color:	Red	Luminous Intensity:	Customers' Requirements
Luminous Flux(lm):	15-20LM	Power:	0.5W
Viewing Angle(°):	120 Degree	Color Rendering Index:	Null
Color Temperature:	620-625NM	Operating Temperature:	-20 - 85
Chip Brand:	Epistar Chip, Sanan Chip,Epileds Chip	Current:	150mA
Voltage:	2.0-2.4V	Warranty:	2 Years
Lifespan:	50000-100000H

Ultra Bright plcc-6 smd 5050 led chips single chip red color 0.5w with 620-625nm

l Emitting Color:Red

l Lens Type:Water Clear

l Device Outline:5.0×5.0×1.1 (unit:mm)

lRoHS compliant

Features:

P-LCC package.
Lead frame package with individual 6 pins.
Available on tape and reel (12mm Tape).
White SMT package.
Super luminosity white LED.
Built in 3 LED chips.
The Chips can be controlled separately.
Optical indicator.
Colorless clear window.
Ideal for backlight and light pipe application.
Inter reflector.
Low current (2mA) operation.
High performance.
Wide viewing angle.
Suitable for vapor-phase reflow, infrared reflow and wave solder processes.
Computable with automatic placement equipment.
The product itself will remain within RoHS complaint Version.

Descriptions:

The 5050 is available in soft orange, green, blue and yellow. Due to the package design, the LED has wide viewing angle and optimized light coupling by inter reflector, this feature makes the SMT TOP LED ideal for light pipe application. The low current requirement makes this device ideal for portable equipment or any other application where power is at a premium.

Applications:

Automotive: Backlight in dashboards and switches.
Telecommunication: Indicator and backlight in telephone and fax.
Indicator and backlight for audio and video equipment.
Indicator and backlight in office and family equipment.
Flat backlight for LCD’s, switches and symbols.
Light pipe application.
General use.

5050 smd led chip red color 620-625nm for led growing light

Electrical and optical characteristics(Ta = 25℃):

Parameter	Symbol	Test Condition	Value			Unit
Parameter	Symbol	Test Condition	Min.	Typ.	Max.	Unit
Forward Voltage	VF	IF = 150mA	--	2.0	2.4	V
Reverse Current	IR	VR = 5V	--	--	30	μA
Wavelength	Tc	IF = 150mA	620	--	630	nm
Luminous Intensity	IV	IF = 150mA	15		20	lm
Viewing Angle	2θ1/2	IF = 150mA	--	120	--	Deg.
