High Voltage SMD 7030 LED , Led Smd 7030 450 - 460 Nm Light Sanan Chip

Product Details:
Place of Origin: SHENZHEN
Brand Name: Yuhang
Certification: CE.SGS.ROHS
Model Number: YHHV7030B1
Delivery Time: 5-7 work days
Payment Terms: T/T, Western Union,Paypal
Supply Ability: 8KK/Days

Detailed Product Description

Type:	smd led	Chip Material:	InGaN
Emitting Color:	Blue	Luminous Intensity:	Customers' Requirements
Luminous Flux(lm):	25-30LM	Power:	1W
Viewing Angle(°):	120 Degree	Color Rendering Index:	Null
Color Temperature:	450-460NM	Operating Temperature:	-20 - 85
Chip Brand:	Epistar Chip, Sanan Chip,Epileds Chip	Current:	150mA
Voltage:	6-7V	Warranty:	2years
Lifespan:	50000-100000Hours

High voltage 6v 1w power smd 7030 led blue color with 450-460nm light sanan chip

Features:

PLCC-2 package.
High power LED type.
White package.
Optical indicator.
Colorless clear window.
Ideal for backlight and light pipe application.
Inter reflector.
Wide viewing angle.
Very long operating life.
Instant light (less than 100 ns).
Reading lights (car, bus, aircraft).
Mini_ accent/Up lighters/Down lighters/Orientation.
Bollards/Security/Garden.
Cove/Under shelf/Task.
Automotive rear combination lamps.
Indoor/Outdoor Commercial and Residential Architectural.
Edge_ lit signs (Exit, point of sale).
LCD Backlights/Light Guides.
Designed for high current operation.
Low thermal resistance.
Suitable for automatic placement equipment.
Suitable for vapor-phase reflow, Infrared reflow and wave solder processes.
The product itself will remain within RoHS compliant Version.

Applications:

Horticultural operations
Commercial vegetable and flower production
Supplemental greenhouse lighting
Hydroponics
Research experiment

Notes:

All dimensions are in millimeters.
Tolerance is ± 0.10mm (.004″) unless otherwise noted.

Specifications are subject to change without notice.

Part No.	Chip Material	Lens Color	Source Color
YHHV7030B1	AlGaInP	Water Clear	Blue

Product Description

Package Dimensions

High Voltage SMD 7030 LED , Led Smd 7030 450 - 460 Nm Light Sanan Chip

Recommended Soldering Patter

SURFACE MOUNT LED LAMPS
Product Type:YHHV7030B1
Absolute maximum ratings (Ta=25°C)
Parameter			Symbol			Value			Unit
Forward current			If			150			mA
Reverse voltage			Vr			--			V
Power dissipation			Pd			960			MW
Operating temperature range			Top			-25~+80			°C
Storage temperature range			Tstg			-30~+85			°C
Peak pulsing current(1/8 duty f=1KHz)			Ifp			200			mA
Junction Temperature			Tj			115			℃/W
Electrostatic Discharge(HBM)			ESD			1000			V
Electro-Optical characteristics (TA=25°C)
Parameter	Test Condition	Symbol		Color	Value					Unit
					Min		Typ	Max
Color Temperature	IF=150mA	CCT		B	--		--	--		K
Forward voltage	IF=150mA	Vf		B	6		--	7		V
luminous flux	IF=150mA	φ		B	25		--	30		LM
Viewing angle at 50% IV	IF=150mA	2θ1/2		B	--		120	--		Deg
Dominant wavelength	IF=150mA	λd		--	450		--	460		nm
Reverse current	Vr=5V	Ir		B	--		--	--		μA
Color Rendering Index	IF=150mA	CRI		--	--		--	--		Ra
