Car Atmosphere Light Smd 7030 Led 0.5 W Jade Green 520-525 NM Low Current

Product Details:
Place of Origin: SHENZHEN
Brand Name: Yuhang
Certification: CE.SGS.ROHS
Model Number: YH7020G05
Delivery Time: 5-7 work days
Payment Terms: T/T, Western Union,Paypal
Supply Ability: 8KK/Days

Detailed Product Description

Type:	smd led	Chip Material:	InGaN
Emitting Color:	Jade-green	Luminous Intensity:	Customers' Requirements
Luminous Flux(lm):	30-40LM	Power:	0.5W
Viewing Angle(°):	120 Degree	Color Rendering Index:	20
Color Temperature:	520-530nm	Operating Temperature:	-20 - 85
Chip Brand:	Epistar Chip, Sanan Chip,Epileds Chip	Current:	150mA
Voltage:	3.0-3.6V	Warranty:	2 Years
Lifespan:	50000-100000Hours

Car atmosphere light smd 7020 led 7030 chip 0.5w jade-green 520-525NM high brightness lamps

Features:

PLCC2 package.
Lead frame package with individual 2 pins.
Available on tape and reel (12mm Tape).
White SMT package.
Super luminosity white LED.
Built in 3 LED chips.
The Chips can be controlled separately.
Optical indicator.
Colorless clear window.
Ideal for backlight and light pipe application.
Inter reflector.
Low current (2mA) operation.
High performance.
Wide viewing angle.
Suitable for vapor-phase reflow, infrared reflow and wave solder processes.
Computable with automatic placement equipment.
The product itself will remain within RoHS complaint Version.

Descriptions:

The YH7020G05 is available in soft orange, green, blue and yellow. Due to the package design, the LED has wide viewing angle and optimized light coupling by inter reflector, this feature makes the SMT TOP LED ideal for light pipe application. The low current requirement makes this device ideal for portable equipment or any other application where power is at a premium.

Applications:

Automotive: Backlight in dashboards and switches.
Telecommunication: Indicator and backlight in telephone and fax.
Indicator and backlight for audio and video equipment.
Indicator and backlight in office and family equipment.
Flat backlight for LCD’s, switches and symbols.
Light pipe application.
General use.

Part No.	Material	Lens Color	Source Color
YH7020G05	InGaN	Water Clear	Jade-green

Notes:

All dimensions are in millimeters (inches).
Tolerance is ± 0.10mm (.004″) unless otherwise specified.

Specifications are subject to change without notice.

Car Atmosphere Light Smd 7030 Led 0.5 W Jade Green 520-525 NM Low Current

Product Description

Package Dimensions

Car Atmosphere Light Smd 7030 Led 0.5 W Jade Green 520-525 NM Low Current

Recommended Soldering Patter

SURFACE MOUNT LED LAMPS
Product Type:YH7020G05
Absolute maximum ratings (Ta=25°C)
Parameter			Symbol			Value			Unit
Forward current			If			150			mA
Reverse voltage			Vr			--			V
Power dissipation			Pd			960			MW
Operating temperature range			Top			-25~+80			°C
Storage temperature range			Tstg			-30~+85			°C
Peak pulsing current(1/8 duty f=1KHz)			Ifp			200			mA
Junction Temperature			Tj			115			℃/W
Electrostatic Discharge(HBM)			ESD			1000			V
Electro-Optical characteristics (TA=25°C)
Parameter	Test Condition	Symbol		Color	Value					Unit
					Min		Typ	Max
Color Temperature	IF=150mA	CCT		G	--		--	--		K
Forward voltage	IF=150mA	Vf		G	3.0		--	3.6		V
luminous flux	IF=150mA	φ		G	30		--	40		LM
Viewing angle at 50% IV	IF=150mA	2θ1/2		G	--		120	--		Deg
Dominant wavelength	IF=150mA	λd		G	520		--	530		nm
Reverse current	Vr=5V	Ir		G	--		--	--		μA
Color Rendering Index	IF=150mA	CRI		G	--		--	--		Ra

Reel Dimensions:

Carrier Tape Dimensions:
Loaded quantity 4000 PCS Per reel.

Car Atmosphere Light Smd 7030 Led 0.5 W Jade Green 520-525 NM Low Current

Application field

Are widely used in the LED lamp, LED bulb light, LED panel light, LED ceiling lamp, LED street light, LED lamp, miner's lamp, stage light, flashlight, lighting, lamp lighting lamps and lanterns, as well as outdoor billboards, such as electronic display, traffic lights, signs, car tail lights, LED modules, LCD back light, LED lighting lighting, LED soft/hard light bar, etc., is the better choice to replace traditional lighting light source.
