Warm White Led 7020 Smd LED Encapsulation Series 2800 - 3200 K ROHS Approved

Product Details:
Place of Origin: SHENZHEN
Brand Name: Yuhang
Certification: CE.SGS.ROHS
Model Number: YH7020WW05
Delivery Time: 5-7 work days
Payment Terms: T/T, Western Union,Paypal
Supply Ability: 8KK/Days

Detailed Product Description

Type:	smd led	Chip Material:	InGaN
Emitting Color:	Warm White	Luminous Intensity:	Customers' Requirements
Luminous Flux(lm):	55-60LM	Power:	0.5W
Viewing Angle(°):	120 Degree	Color Rendering Index:	70
Color Temperature:	Warm White	Operating Temperature:	-20 - 85
Chip Brand:	Epistar Chip, Sanan Chip,Epileds Chip	Current:	150mA
Voltage:	3.0-3.6V	Warranty:	2 Years
Lifespan:	50000-100000Hours

LED Encapsulation Series CRI>70Ra 55-60LM 0.5W 2800-3200k SMD LED 7020 Warm White

Features:

Compatible with automatic placement equipment.
Compatible with infrared and vapor phase reflow solder process.
Mono-color type.
The product itself will remain within RoHS compliant Version.

Descriptions:

The 7020 SMD LED is much smaller than lead frame type components, thus enable smaller board size, higher packing density, reduced storage space and finally smaller equipment to be obtained.
Besides, lightweight makes them ideal for miniature applications, etc.

Applications:

Automotive: Backlighting in dashboard and switch.
Telecommunication: Indicator and backlighting in telephone and fax.
Flat backlight for LCD, switch and symbol.
General use.

Part No.	Material	Lens Color	Source Color
YH7020WW05	InGaN	mix color	Warm white

Notes:

All dimensions are in millimeters (inches).
Tolerance is ± 0.10mm (.004″) unless otherwise specified.

Specifications are subject to change without notice.

Product Description

Package Dimensions

Warm White Led 7020 Smd LED Encapsulation Series 2800 - 3200 K ROHS Approved

Recommended Soldering Patter

SURFACE MOUNT LED LAMPS
Product Type:YH7020WW05
Absolute maximum ratings (Ta=25°C)
Parameter			Symbol			Value			Unit
Forward current			If			150			mA
Reverse voltage			Vr			--			V
Power dissipation			Pd			460			MW
Operating temperature range			Top			-25~+80			°C
Storage temperature range			Tstg			-30~+85			°C
Peak pulsing current(1/8 duty f=1KHz)			Ifp			200			mA
Junction Temperature			Tj			115			℃/W
Electrostatic Discharge(HBM)			ESD			1000			V
Electro-Optical characteristics (TA=25°C)
Parameter	Test Condition	Symbol		Color	Value					Unit
					Min		Typ	Max
Color Temperature	IF=150mA	CCT		WW	2800		--	3200		K
Forward voltage	IF=150mA	Vf		WW	3.0		--	3.6		V
luminous flux	IF=150mA	φ		WW	55		--	60		LM
Viewing angle at 50% IV	IF=150mA	2θ1/2		WW	--		120	--		Deg
Dominant wavelength	IF=150mA	λd		WW	450		--	455		nm
Reverse current	Vr=5V	Ir		WW	--		--	--		μA
Color Rendering Index	IF=150mA	CRI		WW	--		70	--		Ra

Reel Dimensions:

Carrier Tape Dimensions:
Loaded quantity 4000 PCS Per reel.

Warm White Led 7020 Smd LED Encapsulation Series 2800 - 3200 K ROHS Approved

Application field

Are widely used in the LED lamp, LED bulb light, LED panel light, LED ceiling lamp, LED street light, LED lamp, miner's lamp, stage light, flashlight, lighting, lamp lighting lamps and lanterns, as well as outdoor billboards, such as electronic display, traffic lights, signs, car tail lights, LED modules, LCD back light, LED lighting lighting, LED soft/hard light bar, etc., is the better choice to replace traditional lighting light source.
