LED Emitting Diodes Smd Led Types Ultra Blue 450nm 460nm For Indicator Light
Product Details:
Place of Origin: SHENZHEN
Brand Name: Yuhang
Certification: CE.SGS.ROHS
Model Number: YH3020B
Delivery Time: 5-7 work days
Payment Terms: T/T, Western Union,Paypal
Supply Ability: 8KK/Days
Detailed Product Description
| Type: | smd led | Chip Material: | InGaN |
|---|---|---|---|
| Emitting Color: | Blue | Luminous Intensity: | Customers' Requirements |
| Luminous Flux(lm): | 400-500MCD | Power: | 0.06W |
| Viewing Angle(°): | 120 Degree | Color Rendering Index: | Null |
| Color Temperature: | 450-460nm | Operating Temperature: | -20 - 85 |
| Chip Brand: | Epistar Chip, Sanan Chip,Epileds Chip | Current: | 20mA |
| Voltage: | 3.0-3.4V | Warranty: | 2years |
| Lifespan: | 50000-100000H |
SMD 3020 Top View Top LED Emitting Diodes Ultra Blue 450nm 460nm Chip LED for Indicator light
Features:
White package.
Colorless clear window.
Wide viewing angle.
Suitable for vapor-phase reflow, Infrared reflow and wave solder processes.
Compatible with automatic placement equipment.
Available on tape and reel (12 mm Tape).
The product itself will remain within RoHS compliant Version.
Descriptions:
The YH3020B series is available in soft orange, green, blue and yellow. Due to the package design, the LED has wide viewing angle and optimized. Light coupling by inter reflector. This feature makes the TOP View LEDs ideal for portable equipment or any other application where is at a premium.
Applications:
Automotive: Backlight in dashboards and switches.
Telecommunication: Indicator and backlight in telephone and fax
Indicator and backlight for audio and video equipment.
Indicator and backlight in office and family equipment.
Flat backlight for LCD’s, switches and symbols.
Light pipe application.
General use.
| Part No. | Chip Material | Lens Color | Source Color |
| YH3020B | AlGaInP | Water Clear | Ultra Blue |
Product Description
Product features:
1.High lumen: 400-500mcd
2.Low Brightness Decay
3.Stable Performance & Great CCT Inity.
4Color Range:warm white, natural white, cool white.
Product quality:
1.Good raw materials
2. Copper layer
3. Gold wire connection
4.Sanan chips
5. Lifespan is >50 000 hours easily
| SURFACE MOUNT LED LAMPS | |||||||||
| Product Type:YH3020B | |||||||||
| Absolute maximum ratings (Ta=25°C) | |||||||||
| Parameter |
Symbol |
Value | Unit | ||||||
| Forward current |
If |
20 | mA | ||||||
| Reverse voltage | Vr | 5 | V | ||||||
| Power dissipation | Pd | 0.06 | W | ||||||
| Operating temperature range | Top | -25~+80 | °C | ||||||
| Storage temperature range | Tstg | -30~+85 | °C | ||||||
|
Peak pulsing current (1/8 duty f=1KHz) |
Ifp | 40 | mA | ||||||
| Electro-Optical characteristics (TA=25°C) | |||||||||
Parameter |
Test Condition |
Symbol |
Value | Unit | |||||
| Min | Typ | Max | |||||||
| Wavelength | If=20mA | WL | 450 | --- | 460 | K | |||
| Forward voltage | If=20mA | Vf | 3 | -- | 3.4 | V | |||
| luminous flux |
If=20mA |
φ | 400 | -- | 500 | MCD | |||
|
Viewing angle at 50% IV |
If=20mA | 2θ1/2 | -- | 120 | -- | Deg | |||
|
Color rendering index |
If=20mA |
CRI | -- | -- | -- | Ra | |||
| Reverse current | Vr=5V | Ir | -- | 5 | -- | μA | |||
Our advantages
Application field
Are widely used in the LED lamp, LED bulb light, LED panel light, LED ceiling lamp, LED street light, LED lamp, miner's lamp, stage light, flashlight, lighting, lamp lighting lamps and lanterns, as well as outdoor billboards, such as electronic display, traffic lights, signs, car tail lights, LED modules, LCD back light, LED lighting lighting, LED soft/hard light bar, etc., is the better choice to replace traditional lighting light source.
