60 MA Current Smd 5730 Chip , Chip Led 5730 0.2 Watt Apply To Downlight

Product Details:
Place of Origin: SHENZHEN
Brand Name: Yuhang
Certification: CE.SGS.ROHS
Model Number: YH5730MR02
Delivery Time: 5-7 work days
Payment Terms: T/T, Western Union,Paypal
Supply Ability: 8KK/Days

Detailed Product Description

Type:	smd led	Chip Material:	InGaN
Emitting Color:	Mix Red	Luminous Intensity:	Customers' Requirements
Luminous Flux(lm):	8-10LM	Power:	0.2W
Viewing Angle(°):	120 Degree	Color Rendering Index:	40
Color Temperature:	1000-1100K	Operating Temperature:	-20 - 85
Chip Brand:	Epistar Chip, Sanan Chip,Epileds Chip	Current:	60mA
Voltage:	3.0-3.4V	Warranty:	2 Years
Lifespan:	50000-100000H

New design 60mA YH-5730R SMD LED 0.2W Red 620-630nm color for led downlight

Features:
PLCC-2 package.
White package.
Optical indicator.
Colorless clear window.
Ideal for backlight and light pipe application.
Inter reflector.
Wide viewing angle.
Suitable for automatic placement equipment.
Suitable for vapor-phase reflow, Infrared reflow and wave solder processes.
Available on tape and reel (8mm Tape).
The product itself will remain within RoHS compliant Version.

Descriptions:

The 5730 series is available in soft red, orange, yellow, green, blue and white. Due to the package design, the LED has wide viewing angle and optimized light coupling by inter reflector. This feature makes the SMT TOP LED ideal for light pipe application. The low current requirement makes this device ideal for portable equipment or any other application where power is at a premium.

Applications:

Automotive: Backlighting in dashboards and switches.
Telecommunication: Indicator and backlight in telephone and fax
Indicator and backlight for audio and video equipment.
Indicator and backlight in office and family equipment.
Flat backlight for LCD’s, switches and symbols.
Light pipe application.
General use.

Package Dimension:
60 MA Current Smd 5730 Chip , Chip Led 5730 0.2 Watt Apply To Downlight

Recommended Soldering Patter

Part No.	Chip Material	Lens Color	Source Color
YH5730MR02	InGaN	YellowDiffused	Mix Red

5730 smd led Perfect Product Package—We Care about Your Goods and You

Product Type:YH5730MR05
Absolute maximum ratings (Ta=25°C)
Parameter			Symbol			Value		Unit
Forward current			If			60		mA
Reverse voltage			Vr			5		V
Power dissipation			Pd			230		MW
Operating temperature range			Top			-25~+80		°C
Storage temperature range			Tstg			-30~+85		°C
Peak pulsing current (1/8 duty f=1KHz)			Ifp			80		mA
Electro-Optical characteristics (TA=25°C)
Parameter	Test Condition	Symbol		Value					Unit
				Min	Typ		Max
Color Temperature	If=60mA	CCT		1000	--		1100		K
Forward voltage	If=60mA	Vf		3.0	--		3.6		V
luminous flux	If=60mA	φ		8	--		10		Lm
Viewing angle at 50% IV	If=60mA	2θ1/2		--	120		--		Deg
Dominant wavelength	If=60mA	λd		450	--		452		nm
Reverse current	Vr=5V	Ir		--	5		--		μA

Reel Dimensions:

Carrier Tape Dimensions:
Loaded quantity 3000 PCS Per reel.

60 MA Current Smd 5730 Chip , Chip Led 5730 0.2 Watt Apply To Downlight

Application field

Are widely used in the LED lamp, LED bulb light, LED panel light, LED ceiling lamp, LED street light, LED lamp, miner's lamp, stage light, flashlight, lighting, lamp lighting lamps and lanterns, as well as outdoor billboards, such as electronic display, traffic lights, signs, car tail lights, LED modules, LCD back light, LED lighting lighting, LED soft/hard light bar, etc., is the better choice to replace traditional lighting light source.
