Double Chip LED SMD 5730 White And Yellow 1W Led Chip For Led Car Turn Signal

Product Details:
Place of Origin: SHENZHEN
Brand Name: Yuhang
Certification: CE.SGS.ROHS
Model Number: YH5730YW1
Delivery Time: 5-7 work days
Payment Terms: T/T, Western Union,Paypal
Supply Ability: 8KK/Days

Detailed Product Description

Type:	smd led	Chip Material:	InGaN
Emitting Color:	White/Yellow	Luminous Intensity:	Customers' Requirements
Luminous Flux(lm):	W:55-60LM/Y:10-15LM	Power:	1W
Viewing Angle(°):	120 Degree	Color Rendering Index:	80
Color Temperature:	W:6000-6500K /Y:590-595NM	Operating Temperature:	-20 - 85
Chip Brand:	Epistar Chip, Sanan Chip,Epileds Chip	Current:	Single Color 150mA
Voltage:	Y:2.0-2.4V/W:3.0-3.4V	Warranty:	2 Years
Lifespan:	50000-100000H

Dual Colors Double Chip Bi-color 5730 SMD LED White + Yellow 1W led chip for led Car turn signal

Features:

PLCC-2 package.
High power LED type.
Very long operating life.
Bi-color led (Yellow+White)
Instant light(less than 100ns).
Designed for high current operation.
Low thermal resistance.
High reliable
The product itself will remain within RoHS compliant Version

Descriptions:

The 5730YW1 series is specially designed for applications requiring higher brightness.
The LED lamps are available with different colors,intensities.
Utilizing advanced Silicon Chip-carrier chip technology.

Applications:

Reading lights (car, bus, aircraft).
Portable(flashlight,bicycle).
Mini accent/Up lighters/Down lighters/Orientation..
Bollards/Security/Garden.
Cove/Under shelf/Task
Automotive rear combination lamps.
Indoor/Outdoor Commercial and Residential Architectural.
Traffic signaling/Beacons/Rail crossing and Wayside.
Edge_ lit signs (Exit, point of sale).
LCD Backlights/Light Guides.

Package Dimensions

Double Chip LED SMD 5730 White And Yellow 1W Led Chip For Led Car Turn Signal

Recommended Soldering Patter

Double Chip LED SMD 5730 White And Yellow 1W Led Chip For Led Car Turn Signal

Product Type:YHHE5730YW1
Absolute maximum ratings (Ta=25°C)
Parameter			Symbol			Value		Unit
Forward current			If			300		mA
Reverse voltage			Vr			5		V
Power dissipation			Pd			0.5		W
Operating temperature range			Top			-25~+80		°C
Storage temperature range			Tstg			-30~+85		°C
Peak pulsing current (1/8 duty f=1KHz)			Ifp			350		mA
Electro-Optical characteristics (TA=25°C)
Parameter	Test Condition	Symbol		Value					Unit
				Min	Typ		Max
Color Temperature	If=150mA	CCT		6000	--		6500		K
Forward voltage	If=150mA	Vf		3.0 2.0	--		3.4 2.4		V
luminous flux	If=150mA	φ		55 10	--		60 15		Lm
Viewing angle at 50% IV	If=150mA	2θ1/2		--	120		--		Deg
Dominant wavelength	If=150mA	λd		590	--		595		nm
Reverse current	Vr=5V	Ir		--	5		--		μA

Double Chip LED SMD 5730 White And Yellow 1W Led Chip For Led Car Turn Signal

Reel Dimensions:

Carrier Tape Dimensions:
Loaded quantity 3000 PCS Per reel.

Double Chip LED SMD 5730 White And Yellow 1W Led Chip For Led Car Turn Signal

Application field

Are widely used in the LED lamp, LED bulb light, LED panel light, LED ceiling lamp, LED street light, LED lamp, miner's lamp, stage light, flashlight, lighting, lamp lighting lamps and lanterns, as well as outdoor billboards, such as electronic display, traffic lights, signs, car tail lights, LED modules, LCD back light, LED lighting lighting, LED soft/hard light bar, etc., is the better choice to replace traditional lighting light source.
