High Brightness 3014 Led Chip 120 Deg 0.1 Watt 450 Nm 460 Nm Royal Blue

Product Details:
Place of Origin: SHENZHEN
Brand Name: Yuhang
Certification: CE.SGS.ROHS
Model Number: YH3014B
Delivery Time: 5-7 work days
Payment Terms: T/T, Western Union,Paypal
Supply Ability: 8KK/Days

Detailed Product Description

Type:	smd led	Chip Material:	InGaN
Emitting Color:	Blue	Luminous Intensity:	Customers' Requirements
Luminous Flux(lm):	700-900MCD	Power:	0.1W
Viewing Angle(°):	120 Degree	Color Rendering Index:	Null
Color Temperature:	450-460nm	Operating Temperature:	-20 - 85
Chip Brand:	Epistar Chip, Sanan Chip,Epileds Chip	Current:	30mA
Voltage:	3.0-3.4V	Warranty:	2years
Lifespan:	50000-100000H

High bright 120 Deg 0.1 Watt 450nm 460nm royal blue/blue 3014 smd led specifications

PLCC-2 package.
White package.
Optical indicator.
Colorless clear window.
Ideal for backlight and light pipe application.
Inter reflector.
Wide viewing angle.
Suitable for automatic placement equipment.
Suitable for vapor-phase reflow, Infrared reflow and wave solder processes.
Available on tape and reel (8mm Tape).
The product itself will remain within RoHS compliant Version.
Descriptions:
The YH3014B series is available in soft red, orange, yellow, green, blue and white. Due to the package design, the LED has wide viewing angle and optimized light coupling by inter reflector. This feature makes the SMT TOP LED ideal for light pipe application. The low current requirement makes this device ideal for portable equipment or any other application where power is at a premium.
Applications:
Automotive: Backlighting in dashboards and switches.
Telecommunication: Indicator and backlight in telephone and fax
Indicator and backlight for audio and video equipment.
Indicator and backlight in office and family equipment.
Flat backlight for LCD’s, switches and symbols.
Light pipe application.
General use.

High Brightness 3014 Led Chip 120 Deg 0.1 Watt 450 Nm 460 Nm Royal Blue

Part No.	Chip Material	Lens Color	Source Color
YH3014B	InGaN	Clear Diffused	Blue

Product Description

High Brightness 3014 Led Chip 120 Deg 0.1 Watt 450 Nm 460 Nm Royal Blue

Product features:

1. High lumen: 700-900mcd
2. Low Brightness Decay
3. Stable Performance & Great CCT Inity.
4 Color Range:warm white, natural white, cool white,RGB.

Product quality:

1.Good raw materials
2. Copper layer
3. Gold wire connection

4.Sanan chips
5. Lifespan is >50 000 hours easily

SURFACE MOUNT LED LAMPS
Product Type:YH3014B
Absolute maximum ratings (Ta=25°C)
Parameter			Symbol			Value		Unit
Forward current			If			30		mA
Reverse voltage			Vr			5		V
Power dissipation			Pd			0.1		W
Operating temperature range			Top			-25~+80		°C
Storage temperature range			Tstg			-30~+85		°C
Peak pulsing current (1/8 duty f=1KHz)			Ifp			50		mA
Electro-Optical characteristics (TA=25°C)
Parameter	Test Condition	Symbol		Value					Unit
				Min	Typ		Max
Wavelength	If=30mA	WL		450	---		460		K
Forward voltage	If=30mA	Vf		3	--		3.4		V
luminous flux	If=30mA	φ		700	--		900		MCD
Viewing angle at 50% IV	If=30mA	2θ1/2		--	120		--		Deg
Color rendering index	If=30mA	CRI		--	--		--		Ra
Reverse current	Vr=5V	Ir		--	5		--		μA

Our advantages

High Brightness 3014 Led Chip 120 Deg 0.1 Watt 450 Nm 460 Nm Royal Blue

Application field

Are widely used in the LED lamp, LED bulb light, LED panel light, LED ceiling lamp, LED street light, LED lamp, miner's lamp, stage light, flashlight, lighting, lamp lighting lamps and lanterns, as well as outdoor billboards, such as electronic display, traffic lights, signs, car tail lights, LED modules, LCD back light, LED lighting lighting, LED soft/hard light bar, etc., is the better choice to replace traditional lighting light source.
