Strip Lighting IC WS2811 DC 5v Led Chip Inter Reflector Low Current Operation

Product Details:
Place of Origin: SHENZHEN
Brand Name: Yuhang
Certification: CE.SGS.ROHS
Model Number: YHWS2812B
Delivery Time: 5-7 work days
Payment Terms: T/T, Western Union,Paypal
Supply Ability: 8KK/Days

Detailed Product Description

Type:smd ledChip Material:InGaN
Emitting Color:RGBLuminous Intensity:Customers' Requirements
Luminous Flux(lm):High BrightnessPower:0.2W
Viewing Angle(°):120 DegreeColor Rendering Index:Null
Color Temperature:R:620NM G:520NM B:460NMOperating Temperature:-20 - 85
Chip Brand:Epistar Chip, Sanan Chip,Epileds ChipCurrent:60mA
Voltage:5VWarranty:2 Years
Lifespan:50000-100000H


 For Strip Lighting With IC WS2811 DC5V Diode WS2812B SMD 5050 5V RGB LED Chip

  • Features:

  • P-LCC-4 package.

  • White package.

  • Optical indicator.

  • Colorless clear window.

  • Ideal for backlight and light pipe application.

  • Inter reflector.

  • Low current (2mA) operation.

  • Wide viewing angle.

  • Suitable for vapor-phase reflow, infrared reflow and wave solder processes.

  • Computable with automatic placement equipment.

  • Available on tape and reel (12mm Tape).

  • The product itself will remain within RoHS compliant Version.



  • Descriptions:

  • The 5050 is available in soft red, orange, yellow, green, blue and white. Due to the Package design, the LED has wide viewing angle and optimized light coupling by inter reflector, this feature makes the SMT TOP LED ideal for light pipe Application. The low current requirement makes this device ideal for portable equipment or any other application where power is at a premium.

Package Dimensions

Strip Lighting IC WS2811 DC 5v Led Chip Inter Reflector Low Current Operation

  • Applications:

  • Automotive: Backlight in dashboards and switches.

  • Telecommunication: Indicator and backlight in telephone and fax.

  • Indicator and backlight for audio and video equipment.

  • Indicator and backlight in office and family equipment.

  • Flat backlight for LCD’s, switches and symbols.

  • Light pipe application.

  • General use.



  • Reliability Test Items And Conditions (Per Chip):

  • The reliability of products shall be satisfied with items listed below:

    Confidence level: 90%.

    LTPD: 10%.

    1) Test Items and Results:

    No.Test ItemTest Hours/CyclesTest ConditionsSample SizeAc/Re
    1Resistance to Soldering Heat6 Min

    Tsld=260±5℃,

    Min. 5sec

    25pcs0/1
    2Thermal Shock300 Cycles

    H: +100℃ 5min ∫ 10 sec

    L: -10℃ 5min

    25pcs0/1
    3Temperature Cycle300 Cycles

    H: +100℃ 15min ∫ 5min

    L: -40℃ 15min

    25pcs0/1
    4High Temperature Storage1000Hrs.Temp: 100℃25pcs0/1
    5DC Operating Life1000Hrs.IF=20mA25pcs0/1
    6Low Temperature Storage1000Hrs.Temp: -40℃25pcs0/1
    7High Temperature/ High Humidity1000Hrs.85℃/85%RH25pcs0/1



    2) Criteria for Judging the Damage:

    ItemSymbolTest ConditionsCriteria for Judgment
    MinMax
    Forward VoltageVFIF=20mA---F.V.*)×1.1
    Reverse CurrentIRVR=5V---F.V.*)×2.0
    Luminous IntensityIVIF=20mAF.V.*)×0.7---
