High Voltage 3030 SMD LED , 8000 - 10000 K Cool / Warm White 3030 Led Chip

Product Details:
Place of Origin: SHENZHEN
Brand Name: Yuhang
Certification: CE.SGS.ROHS
Model Number: YH3030W
Delivery Time: 5-7 work days
Payment Terms: T/T, Western Union,Paypal
Supply Ability: 8KK/Days

Detailed Product Description

Type:	smd led	Chip Material:	InGaN
Emitting Color:	Cool White	Luminous Intensity:	Customers' Requirements
Luminous Flux(lm):	110-120LM	Power:	1W
Viewing Angle(°):	120 Degree	Color Rendering Index:	80
Color Temperature:	8000-10000K	Operating Temperature:	-20 - 85
Chip Brand:	Epistar Chip, Sanan Chip,Epileds Chip	Current:	150mA
Voltage:	6-6.5V	Warranty:	2 Years
Lifespan:	50000-100000H

Epistar Chip SMD 3030 led cool/warm white 1W high voltage 110-120LM 3V 6V 9V 18V 36v 48v led package

Specification

Setting Information
Item name	3030 smd led high voltage
voltage	6.0-6.5V
Current	150mA
light color	warm white ,natural white,cool white
Size	3.03.00.8mm
temperature	2700-20000K
Chip	Epistar,Sanan
Working life	50000 hours

Variations Available
Power	1W
luminous Flux	110-120LM
CCT	WARM WHITE 2800-3300K NATURAL WHITE 4000-5000K DAYLIGHT WHITE 5000-5500K COOL WHITE >7000K
CRI	80
SMD Models	3030

Variations Available

Power

luminous Flux

110-120LM

CCT

WARM WHITE 2800-3300K

NATURAL WHITE 4000-5000K

DAYLIGHT WHITE 5000-5500K

COOL WHITE >7000K

CRI

SMD Models

3030

Product Description

High Voltage 3030 SMD LED , 8000 - 10000 K Cool / Warm White 3030 Led Chip

SURFACE MOUNT LED LAMPS
Product Type:YHW3030-150MA
Absolute maximum ratings (Ta=25°C)
Parameter			Symbol			Value			Unit
Forward current			If			150			mA
Reverse voltage			Vr			--			V
Power dissipation			Pd			950			mW
Operating temperature range			Top			-25~+80			°C
Storage temperature range			Tstg			-30~+85			°C
Peak pulsing current(1/8 duty f=1KHz)			Ifp			200			mA
Junction Temperature			Tj			115			℃/W
Electrostatic Discharge(HBM)			ESD			1000			V
Electro-Optical characteristics (TA=25°C)
Parameter	Test Condition	Symbol		Color	Value					Unit
					Min		Typ	Max
Color Temperature	IF=150mA	CCT		W	8000		--	10000		K
Forward voltage	IF=150mA	Vf		W	6		--	7		V
luminous flux	IF=150mA	φ		W	110		--	120		LM
Viewing angle at 50% IV	IF=150mA	2θ1/2		W	--		120	--		Deg
Dominant wavelength	IF=150mA	λd		--	--		--	--		nm
Reverse current	Vr=8V	Ir		W	--		--	--		μA
Color Rendering Index	IF=150mA	CRI		--	--		80	--		Ra
